・Two Intel ® Core™ i7-4700EQ CPUs: 　- Four cores, eight threads per CPU 　- Two channels ECC 1600-DDR3L 　- 16GBytes DDR3L, 32GB future option 　- AVX2.0 Advanced Vector Extensions 　- HD-4600 on-chip graphics ・Two platform controller hubs: 　- 16MBytes BIOS Flash per PCH 　- 16GB SATA Nand Flash 　- 512KB NVRAM ・Platform Security: 　- Configurable Security Hub FPGA 　- Intel Trusted Execution 　- Intel vPRO / AMT technology 　- Intel AES new instructions ・Firmware support: 　- Built-in Test 　- UEFI BIOS ・Operating System Support: 　- Linux® SDK 　- Windows ® SDK 　- WRS VxWorks ® BSP 　- WRS Hypervisor ・Middlewares and Libraries: 　- AXISPro application development framework 　- AXISLib VSIPL and RSPL multi-threaded DSP and math libraries for VxWorks, Linux & Windows 　- GE signal- and image processing quick start examples 　- Intel OpenCL SDKs, IPP and MKL

・Dual Intel® 2nd Generation Quad Core™ i7 Processors 　- Intel® Advanced Vector Extensions (AVX) 　- Intel® Hyper-Threading Technology 　- Intel® HD Graphics 3000 with 3D & OpenGL 　- Intel® Turbo Boost 2.0 at up to 3 GHz 　- Trusted Platform Module (TPM) ・Two CPU sub-systems each with: 　- 6 MBytes shared L3 Cache 　- 8 GigaBytes DDR3 SDRAM (16 GB total) 　- Dual port RDMA NIC-10GE & DDR Infiniband ・Mobile Intel® QM67 Express PCH: 　- 4MB SPI FLASH plus recovery BANC FLASH 　- 512KB MRAM NV memory for mission data 　- 8 GigaBytes NAND FLASH Disk 　- HDMI/DVI Display port 　- 2 x USB 2.0 ports 　- SATA 3.0 interface 　- 2 x RS232/422/485 serial ports 　- 8 x GPIO 　- PS2 keyboard & mouse ・6U OpenVPX VITA65 Payload profile with: 　- Data Plane: 10GE/Infiniband RDMA NICs 　- Expansion Plane: Gen 2 PCIe Switch with DMA 　- Control Plane: 2 x GbE ports per node

・Four Freescale 8640D SoC nodes ・Eight banks DDR2 SDRAM ・Eight port Serial RapidIO switch ・Forty-eight lane gen_2 PCIe switch ・One PMC-X / XMC (VITA 42.3) site ・Gigabit Ethernet switch with VLAN ・Eight serial ports ・Rugged 6U VITA 46 & VITA 48/REDI builds ・AXIS Advanced Multiprocessor Integrated Software ・Built-In-Test (BIT) for Power Architecture ・BSPs for LynxOS 5.0 & VxWorks 6.6 ・Linux Software Development Ki

・18 payload [ports) ・4 inter-switch ports ・1 fiber optic front panel port (optional) ・All ports are x4 lanes ・All lanes are 1, 2.5 & 3.125 GHz capable ・MPC8548 management processor ・x4 Serial RapidIO interface to switch fabric Gigabit Ethernet port to front panel ・RS232 serial ports to front panel ・I2CBus interface to all switch nodes ・Rugged 6U VITA 41.2 form factor for air, spray and conduction cooled systems ・VxWorks BSP with API to switch management layer ・GE Intelligent Platforms Built-In-Test (BIT) for PowerPC ・Optional switch management module

・OpenVPX™ (VITA 65) profile MOD6-PAY-4F1Q2U2T-12.2.1-11, VPX REDI (VITA 48 option) ・Single user-programmable Xilinx Virtex-7 FPGAs (X690T or X980T), with 　　・8 GB DDR3L SDRAM in two banks 　　・Four 4-lane serial data plane links to the backplane (support up to 10.3 Gbps data rates) 　　　・Gen2 SRIO or alternate fabrics with different FPGA cores 　　・One 4-lane Gen3 PCIe connection to a Gen3 PCIe switch 　　・One additional x4 10.3 Gbps link to the backplane 　　・16 LVDS pairs to the backplane 　　・Two enhanced FMC interfaces with 128+ differential signal pairs 　　　・One site supports JESD204B or Serial FMCs with up to 8 serial links 　　　・The other site has optional support for up to 160 LVDS pairs with X690T FPGA ・Two Mezzanine sites with support for FMC (VITA 57) or enhanced FMC ・Onboard PCIe Gen3 switch - Two 8-lane expansion plane fabric ports to the backplane with configurable NTB support ・Sensors for monitoring board power consumption ・Support for ChipScope Pro and JTAG processor debug interfaces ・Backplane clock/sync paths to mezzanines sites ・FXTools BSP and FPGA design kit with highly-optimized IP Blocks, development environment, reference designs, scriptable simulation test benches and software libraries VxWorks and Linux variants available ・VITA 48 1” pitch format ・Ruggedization levels 　　・Air-cooled Level 0 (commercial) 　　・Conduction-cooled Level 200 (future) ・Path to variant with Processor (contact factory)

・Two Intel Core i7-3612QE quad-core processors at up to 2.1GHz ・4 Gbytes DDR3 SDRAM with ECC per processor ・8GB NAND flash per processor ・256 Kbytes NVRAM ・Gen2 Serial RapidIO Data Plane interface, 8GB/s bi-directional bandwidth ・Gen2 PCI Express Expansion Plane interface on P2, up to 8GB/s bidirectional bandwidth ・Two 1000BASE-T, two 1000BASE-BX Ethernet interfaces ・One VITA 42.3 XMC mezzanine site ・Four EIA-232, two EIA-422/485 serial ports ・Three USB 2.0 interfaces ・Two SATA interfaces ・Power/Temperature sensors ・VxWorks® BSP supporting SMP ・Linux LSP ・Continuum Vector AVX/SSE optimized DSP function library ・Continuum Insights multi-processor development tools ・Continuum IPC inter-processor communications library ・VITA 65 compliant per MOD6-PAY-4F1Q2U2T-12.2.1-11 ・Rugged air cooled and conduction cooled variants

・3U VPX Carrier Card ・Compatible with VITA 65 module/slot profiles: 　　・MOD3-PER-2F-16.3.1-3 / SLT3-PER-2F-14.3.1 　　・MOD3-PER-1F-16.3.2-2 / SLT3-PER-1F-14.3.2 　　・MOD3-PAY-1D-16.2.6-1 / SLT3-PAY-1D-14.2.6 　　・MOD3-PAY-2F-16.2.7-1 / SLT3-PAY-2F-14.2.7 　　・The board is compatible with payload profiles but has no hosting capabilities ・Available in conduction cooled versions. For air-cooled versions, please contact Curtiss-Wright. ・Supports a single XMC or PMC mezzanine module 　　・PMC site is PCI3.0 compliant, 32/64-bit, 33/66MHz, up to 1GB/s 　　・PMC site is PCI-X 1.0b compliant, 64-bit, 66/100/133MHz, up to 1GB/s 　　・XMC site is PCIe Gen 2.0 and 8 lanes wide 　　・Front or rear panel I/O support for PMC site. Rear I/O is compliant to VITA 46.9 P2w1-P64s.

・4 slot 6U OpenVPX chassis with uncommitted backplane ・3 NVIDIA CUDA GPU's ・Intel Penryn 2.26 GHz Core 2 Duo ・2x 10GE data plane ports ・x16 lane PCIe expansion plane ・2x 1000BaseT & 2 x 1000Base-BX control plane ・2 spare OpenVPX pay load slots ・Rear transition modules & cables supporting multiple data & expansion plane configurations ・4x rotary disk drives ・CentOS 64-bit Linux

1U Open VPX Rackmount platform with two 3U VPX payload slots. Compatible with 0.8-inch, 0.85-inch and 1.0-inch modules Integrated Intel® Xeon® Processor E-2176M (Coffee Lake) PCIe Gen3 x8 to each of the VPX module Dual Display Port (DP) for Video out

・CHAMP-WB or CHAMP-WB-DRFM Xilinx Virtex-7 FPGA processor card with 8GB DDR3L SDRAM ・VPX6-1957 Intel Core i7 Single Board Computer with 8GB of DDR3 SDRAM or CHAMP-AV8 Intel Core i7 Processor Card with 8 GB of DDR3 SDRAM ・OF-SMART6 6U OpenVPX Development Chassis with option for centralized or pass-thru backplanes ・VxWorks or Linux Toolkits
