・Two Intel Core i7-3612QE quad-core processors at up to 2.1GHz ・4 Gbytes DDR3 SDRAM with ECC per processor ・8GB NAND flash per processor ・256 Kbytes NVRAM ・Gen2 Serial RapidIO Data Plane interface, 8GB/s bi-directional bandwidth ・Gen2 PCI Express Expansion Plane interface on P2, up to 8GB/s bidirectional bandwidth ・Two 1000BASE-T, two 1000BASE-BX Ethernet interfaces ・One VITA 42.3 XMC mezzanine site ・Four EIA-232, two EIA-422/485 serial ports ・Three USB 2.0 interfaces ・Two SATA interfaces ・Power/Temperature sensors ・VxWorks® BSP supporting SMP ・Linux LSP ・Continuum Vector AVX/SSE optimized DSP function library ・Continuum Insights multi-processor development tools ・Continuum IPC inter-processor communications library ・VITA 65 compliant per MOD6-PAY-4F1Q2U2T-12.2.1-11 ・Rugged air cooled and conduction cooled variants

Intel Ice Lake Xeon D-1700 10-core Processor with integrated Platform Controller Hub (PCH) Extended operating temperature Intel eTEMP SKUs 64-bit CPU architecture with new AVX512 SIMD engine Dual 10 GbE-KR ports 40 GbE Data Plane 48 GB DDR4 memory controller with transfer rates at 2400 MT/s, 19.2 GBytes per channel Xilinx MPSoC FPGA with embedded dual-A53 processor and 4 GB of DDR4 memory for enhanced security or co-processor functionality Microsemi SmartFusion2 FPGA for Tier2 IPMI with HOST 3.0 support Up to 2-channels of NVMe SSD supporting up to 160 GB SLC/480 GB TLC secure storage Trusted Computing protections Variants aligned with Payload Plug-In Card Profile from SOSA Technical Standard OS support: Alma 8.x Linux, Red Hat Enterprise Linux

・OpenVPX™ (VITA 65) profile MOD6-PAY-4F1Q2U2T-12.2.1-11, VPX REDI (VITA 48 option) ・Single user-programmable Xilinx Virtex-7 FPGAs (X690T or X980T), with 　　・8 GB DDR3L SDRAM in two banks 　　・Four 4-lane serial data plane links to the backplane (support up to 10.3 Gbps data rates) 　　　・Gen2 SRIO or alternate fabrics with different FPGA cores 　　・One 4-lane Gen3 PCIe connection to a Gen3 PCIe switch 　　・One additional x4 10.3 Gbps link to the backplane 　　・16 LVDS pairs to the backplane 　　・Two enhanced FMC interfaces with 128+ differential signal pairs 　　　・One site supports JESD204B or Serial FMCs with up to 8 serial links 　　　・The other site has optional support for up to 160 LVDS pairs with X690T FPGA ・Two Mezzanine sites with support for FMC (VITA 57) or enhanced FMC ・Onboard PCIe Gen3 switch - Two 8-lane expansion plane fabric ports to the backplane with configurable NTB support ・Sensors for monitoring board power consumption ・Support for ChipScope Pro and JTAG processor debug interfaces ・Backplane clock/sync paths to mezzanines sites ・FXTools BSP and FPGA design kit with highly-optimized IP Blocks, development environment, reference designs, scriptable simulation test benches and software libraries VxWorks and Linux variants available ・VITA 48 1” pitch format ・Ruggedization levels 　　・Air-cooled Level 0 (commercial) 　　・Conduction-cooled Level 200 (future) ・Path to variant with Processor (contact factory)

・6U OpenVPX (VITA 65) ・Dual user-programmable Xilinx Virtex-6 FPGAs (SX475T or LX550T), each with: 　　・2 GB DDR3 SDRAM in two banks 　　　・Supports migration to 4 GB per FPGA 　　・72 MB QDRII+ SRAM in four banks ・Freescale Power Architecture MPC8640D processor 　　・Running at 1 GHz 　　・1 GB SDRAM in two banks ・Two Mezzanine sites with support for FMC (VITA 57) ・On-board SRIO 1.3 switch 　　・Four 4-lane fabric ports to the backplane 　　・4-lane ports to both user FPGAs and the MPC8640D processor ・Thermal sensors for monitoring board temperatures ・Sensors for monitoring board power consumption ・Support for ChipScope™ Pro and JTAG processor debug interfaces ・Multi-board synchronous clock ・FusionXF BSP and FPGA design kit with highly-optimized IP Blocks, development environment, reference designs, scriptable simulation test benches and software libraries 　　・VxWorks® and Linux® variants available ・Continuum IPC - inter-processor communications middleware available ・Continuum Vector subroutine library available ・VITA 48 1” pitch format 　　・Ruggedization levels 　　　・Level 0 (Commercial) 　　　・Air-cooled level 100 　　　・Conduction-cooled level 200

・Extreme numerical processing for DSP and general purpose applications ・Reduces size, weight, and power 2-4X over previous generations ・Seamless integration into HPEC systems including FPGA’s, GPGPU’s, Sensor I/O and Middleware ・6U OpenVPX compliant ・Two Intel Core-i7 quad-core 4th generation processors ・614-1318 GFLOPs peak computing performance ・16 GB DDR3 SDRAM with ECC ・Four 40 Gb Ethernet Data Plane interfaces at an aggregate 112 Gbps ・Two 16-lane Gen3 PCI Express Expansion Plane interfaces ・Power management features ・VxWorks BSP and Linux LSP ・Rugged air-cooled and conduction-cooled versions ・Trusted COTS

・Description: 8-10U Rugged Rackmount Enclosures ・Size: 19" Rackmount, 8-10U ・Cooling: Air Cooled Boards & Air Cooled Chassis ・Slot Bus Structure: VPX, OpenVPX, VPX-REDI (VITA 46/48/65/68), VME64x or VXS (VITA 41)

・Form Factor 　　・1 ATR 　　・6U OpenVPX™/VME/Hybrid backplane 　　・Volume optimized – single-slot chassis - 287 (w) x 211 (h) x 420 (d) mm ・Low Weight: Under 20 kg fully populated ・Power Supply 　　・28 VDC or 115 VAC 　　・600 W at 55 °C 　　・310 W at 71 °C ・Subsystem Solutions 　　・Technology refresh – easy retrofit 　　・Signal processing 　　・Video and image processing 　　・And more...

・6U OpenVPX SBC
・Dual/Quad core, 3rd Gen. Intel Core i7 processor @ up to 2.5 GHz
・Intel QM77 Express Chipset
・Up to 16 GB of DDR3 SDRAM w/ECC
・Up to 16 GB NAND Flash
・Dual on-board Expansion sites (XMC/PMC)
・Air and Conduction cooled versions
・Comprehensive Deployed Test Software
・Comprehensive OS support

・6U OpenVPX SBC ・Dual/Quad core, Intel 2nd Gen. Core i7 processor @ up to 2.5 GHz ・Mobile Intel QM67 Express Chipset ・Up to 16 GB of DDR3 SDRAM w/ECC ・Up to 16 GB NAND Flash ・Dual on-board Expansion sites (XMC/PMC) ・Air and Conduction cooled versions ・Comprehensive Deployed Test Software ・Comprehensive OS support

・6U VPX Single Board Computer ・P4080 Power Architecture processor ・Eight e500mc cores @ up to 1.5 GHz ・Dual-channel DDR3 (up to 8 GB) ・512 MB NOR Flash ・4 GB NAND Flash Solid-State Drive ・512 KB non-volatile MRAM ・4off x4 SRIO links from VPX P1 ・4off x4 PCIe Gen2 links from VPX P2 ・2x PMC/XMC Sites ・AFIX site (SCSI/VGA/1553/Flash drive) ・2x 10/100/1000BaseT Ethernet + 2x 10/100/1000BaseT/1000BaseX
