Rugged 6-port 10/100 Ethernet switch • High-performance, rugged Quadrax connector for superior signal integrity • Layer 2+ carrier Ethernet software management Ultra-miniature SWaP-optimized design: Size: ~10 in3 Weight: ~0.55 lb (~0.25 kg) Power: <5W • IEEE-1588v2 Precision Timing Protocol support • Designed to MIL-810G, MIL-461F, MIL-704F compliant

Rugged 20-port Gigabit Ethernet switch • Layer 2+ carrier Ethernet software management • Size, weight and power (SWaP) optimized: + Size: 112 in3 + Weight: 4 lb + Power: < 20W • Low-power, Energy Efficient Ethernet compliant • IEEE-1588v2 Precision Timing Protocol • Qual tested to extreme environment and EMI conditions per DO-160, MIL-810G and MIL-461F • Vehicle and aircraft compatible power supply (per DO-160, MIL-704F and MIL-1275D) • IP67 dust and waterproof aluminum chassis • Circular MIL-DTL-38999 connectors

Rugged 8-port GbE switch • High performance, rugged MIL-circular connectors Overview CURTISSWRIGHTDS.COM The Parvus® DuraNET® 20-11 is an ultra-small form factor (SFF) rugged Commercial Off the Shelf (COTS) 8-port Gigabit Ethernet (GbE) switch optimized for extremely demanding size, weight and power (SWaP) constrained vehicle and aircraft platforms exposed to harsh environmental and noisy electrical conditions (e.g. high altitude, extreme shock and vibration, extended temperatures, humidity, dust and water exposure, noisy EMI, and/or dirty power). The unit boasts an ultra-miniature “pocket-sized” design with a physical size of roughly 10 in3 in volume, 0.50 lb in weight, and 5W typical power consumption. Bringing out Ethernet, power, console, and zeroize signals over micro miniature MIL circular connectors, the unit is well suited for low size and weight applications with demanding electromagnetic compatibility (EMC) requirements. Validated for military and civil aircraft use as well as ground vehicle installations, the 20-11 features integrated EMI and power filtering for the input voltages, spikes, surges, transients, and EMI/EMC compatibility requirements of MIL-STD-704F, MIL-STD 1275D, MIL-STD-461F, and RTCA/DO-160. • Layer 2+ carrier Ethernet software management • Ultra-miniature SWaP optimized design: + Size: 10 in3 (fits in hand) + Weight: 0.50 lb (~0.23 kg) + Power: 5W • PTP (IEEE-1588v2) precision time stamping • Fully validated to MIL-STD-810G/461F/ 704F/1275D and DO-160

Ruggedized Cisco ESS 2020 IOS- managed switch Overview CURTISSWRIGHTDS.COM The Parvus® DuraNET® 30-2020 is an ultra-rugged 19-port Cisco IOS-managed Layer 2+ network switch integrating Cisco’s ESS 2020 Embedded Services Switch technology with an isolated MIL-1275/MIL 704/DO-160 power supply in an IP67 (dust/water proof) sealed aluminum chassis with MIL-DTL-38999 connectors. Designed for size, weight and power (SWaP) sensitive harsh military and civil environments (i.e. aircraft, vehicle, mining, industrial), the unit provides reliable local area network (LAN) switching capabilities with the ease of use, secure access, and manageability expected from Cisco-based technology. Two levels of Cisco IOS® software (LAN Lite or LAN Base) are available to support access layer connectivity and needs for data, security, voice, and video traffic at the network edge for stationary or mobile network nodes. Validating its robust Information Assurance (IA) and network interoperability, the DuraNET 30 2020 has been US DoD Unified Capabilities Approved Product List (UC APL) certified. • 19 ports (2x GigE uplinks, 17x Fast Ethernet) • Cisco IOS Layer 2+ LAN-Base/LAN-Lite software • SWaP-optimized subsystem: + Size: <2U height - 3.0” (7.6cm) + Weight: 4.2 lb (1.9 kg) + Power: < 10 W • Migration path for Catalyst 2955T-12 systems • Qual-tested to MIL-STD-810G, MIL-STD-461F, and RTCA/DO-160G • IP67 ingress protection, MIL-DTL-38999 connectors • Vehicle and aircraft compatible power supply (per DO-160G, MIL-STD-704F and MIL-STD-1275D

Ultra-rugged Cisco ESR-6300-based secure network router/switch 6 x GbE ports (2 x WAN, 4 x LAN) Cisco IOS-XE Network Essentials or Network Advantage software SWaP optimized: – Small size: ~55 in³ in volume– Lightweight: ~ 2 lb (0.91 kg) – Low-power: < 25 watts (est) Waterproof IP67 chassis with circular MIL-performance connectors MIL-1275/704/DO-160 power supply for aicraft and ground vehicles MIL-STD-810G, MIL-STD-461F and DO-160 qualifications Supports Layer 3 CNSA / IPSEC encryption, VPN, Firewall, NAT, QoS, MANET, RAR

SWaP-C Optimized Rugged Network Switch Extremely small footprint and <5lb 15 Watts typical power 16-port Gigabit Ethernet Switch Non-blocking architecture supports tri speed operation (10/100/1000Mbps) with auto-negotiation and auto-MDIX Full support for IPv4 and IPv6 networks Port, MAC, and protocol-based VLANs Spanning Tree support (RSTP, MSTP) Multicast support (IGMP/MLD snooping) Quality of Service (QoS) Support for jumbo frames up to 9KB Link aggregation, Port mirroring Static routing is also supported for IP routing to attached WAN/radio ports Energy Efficient Ethernet (EEE) per 802.3az with built-in cable diagnostics Hardware support for IEEE-1588v2 and Precision Time Protocol (PTP) Powerful in-band (HTTP/Telnet/SNMP) and out-of-band (RS-232) switch configuration and management

26-port L2/L3 switch (24x 1000Base-T + 2x 10GBase-SR optical ports) • Cisco ESS-3300 rugged embedded switch cards with IOS-XE management • Power Over Ethernet (PoE) injection • Rugged SWaP-optimized design: + Size: < 150 in³ volume; < 3U tall + Weight: ~ 6.0 lb (2.72 kg) + Power: < 50 W (est), excluding PoE • Comprehensive Layer 2/3 switching, QoS, IP multicast, security and management • Rugged IP67 chassis with MIL performance circular connectors • 28 VDC filtered MIL-STD-1275/704/ DO-160 power supply for “dirty power” of aircraft / ground vehicles • MIL-STD-810G/DO-160 thermal, shock, vibration, altitude, humidity; also MIL-STD-461F/DO-160G EMI/EMC

16 Ethernet ports • Support for hardware-based Precision Time Protocol (IEEE-1588v2) • NXP® i.MX6 quad-core Arm Cortex-A9 processor • 2 GB DDR3 • 16 GB eMMC flash • Optional Internal GB-GRAM (Type I/II) SAASM or M-Code GPS receiver • Chip Scale Atomic Clock • On-board 10 Degrees of freedom Inertial Measurement Unit • 8 independent 1PPS signals out and with serial PNT data

Low-power multi-core Arm vetronics processor and network switch • Support for optional integrated military GPS receiver Overview CURTISSWRIGHTDS.COM The DBH-672 Digital Beachhead™ is a rugged, Commercial Off the-Shelf (COTS) single-box solution integrating a Gigabit Ethernet (GbE) switch and low-power Arm® vetronics processor in a MIL-STD qualified, small form-factor (SFF) chassis. The multi-function DBH 672 builds on Curtiss-Wright’s market leadership in SFF system solutions, adding a lower size, weight, power and cost (SWaP-C) design to the Digital Beachhead family capable of consolidating network switch, vehicle processor, embedded GPS, solid-state storage, and add-in I/O interface all in a single Line Replaceable Unit (LRU). Featuring 16 ports of fully managed Layer 2 GbE switching and static Layer 3 routing together with a quad-core Arm i.MX6 Quad processor, the DBH-672 system supports general-purpose embedded computing and in-vehicle edge networking requirements. • SWaP optimized and qual-tested to meet extreme environment/EMI conditions • Filtered MIL-STD-1275D / 704F power supply • Rugged IP67 aluminum chassis with MIL-38999 connectors Applications • Situational awareness upgrades at the network edge • Ethernet switch and shared services processor for ground vehicles • In-vehicle precision time-stamped GbE LAN switching • C4ISR technology refresh and vehicle modernization • HUMS for fleet logistics • Low-power Arm embedded computing applications • Modular open architecture, LRU consolidation

SWaP-C optimized network switch and vehicle management computer: + Size: 10.5 x 7.5 x 3.0” (266 x 190 x 76mm) + Weight: 6.5 lb (3.0 kg) + Power: 28W max • 16-port Gigabit Ethernet switch • Vehicle management computer with f lexible vetronics interfaces • VICTORY architecture • Designed for rugged applications and environments
